Staircase & Lift all in One Product

Description

Revolutionary, totally hidden and totally unique. Whilst idle, the Flexstep is a staircase with open treads and it is virtually impossible to see what lies within. However, once a wall button or remote control is pressed, it transforms into a vertical platform lift (sometimes referred to as a Steplift). This is the optimum solution for any application where the customer does not want to see a lift. It is also perfect for retail settings as it negates the need for both a lift and a fixed set of stairs (Flexstep occupies half of the floor space). Available with a choice of frame colours, handrails and tread inserts (including the customers own), Flexstep meets the needs of even the most discerning of clients.


Technical Details

Application:
Indoors & Outdoors
Maximum Travel:
1.25m / 2 stops
Minimum Platform Size:
700mm x 1155mm (not Part M Compliant)
Maximum Platform Size:
1000mm x 1830mm
Rated Load:
400kg
Pit Depth:
N/A (automatic ramp on platform)
Travel Speed:
0.15m/sec
Headroom:
N/A
Entrance Configuration(s):
Through Access
Door Type(s):
Single Swing or Automatic Rising Barrier
Flooring Type(s):
Choice of Step Inserts / Customers own Materials
Lift Colours / Finishes:
GRIS Sable 900 Grey (std) or RAL colour of your choice
Internal Finishes:
N/A
Fixing Method(s):
Floor Mounted and at Threshold
Power Supply Requirement:
220v Single Phase
Conformity:
European Machinery Directive
Country of Manufacture:
Denmark
