Description

If you would prefer not see lift guides, masts or columns then Easylift is the perfect solution. Using the same proven technology as the award winning Flexstep, Easylift raises and lowers on four legs that are hidden within the side frames of the lift and appear under the lift during travel. This drive method means that Easylift is the narrowest of all Steplifts available today. Both the half height door on the lift platform and the one fixed on the upper landing operate automatically (powered) when the landing is reached. Easylift can be provided in a colour of your choice and there are also various glass tints available.

Technical Details

Application:

Indoors & Outdoors

Maximum Travel:

1.25m / 2 stops

Minimum Platform Size:

800mm x 1400mm

Maximum Platform Size:

1100 x 1400mm

Rated Load:

400kg

Pit Depth:

70mm (or can be floor mounted with a ramp)

Travel Speed:

0.15m/sec

Headroom:

N/A

Entrance Configuration(s):

Through Access

Door Type(s):

Single Swing or Automatic Rising Barrier

Flooring Type(s):

Altro Non-Skid

Lift Colours / Finishes:

GRIS Sable 900 Grey (std) or RAL colour of your choice

Internal Finishes:

N/A

Fixing Method(s):

Floor Mounted and at Threshold

Power Supply Requirement:

220v Single Phase

Conformity:

European Machinery Directive

Country of Manufacture:

Denmark
